02-355057Â DANFOSSÂ |Â PROPORTIONAL VALVE
Manufacturer:Â DANFOSS
Manufacturer Model #:Â 02-355057
EATON PROPORTIONAL VALVES
Rated flows up to 160 L/min (42 USgpm)|Reliable, economical and compact|Maximum flexibility and minimum space
Rated flows up to 160 L/min (42 USgpm)|Reliable, economical and compact|Maximum flexibility and minimum space
- Application: Harvesters, refuse haulers, mobile and industrial applicationsCavity: C-16-3SCoil termination: DIN43650Diode: NoEccn: EAR99Flow direction: Nose in-Side outFlow rate12: 60 litre per minuteFluid compatibility13: MIL–H–5606, SAE 10, SAE 20, etcHousing: YesHousing material: AluminumIcc2: SICV Proportional ValvesInstallation type: Screw-in CartridgeLeakage: 50 cc/min at 140 barModel Code: EPV16-A-06-A-12H-N-24D-0-U-13Number of valve ports: 2Operating temperature: -30°C to +90°COverride type: NonePort Size: 12Port type: SAEPressure rating: 280 barProduct height: 9.04Product height uom: inchProduct length: 3.97Product length uom: inchProduct trade name: EPV16 SeriesProduct weight: 2.20Product weight uom: poundProduct width: 2.38Product width uom: inchRecommended filtration level: 15/13/11Seal Type: Buna-NSpecial features17: NoneStyle: Normally ClosedSub brand: VickersVoltage: 24 voltVoltage type22: DCWorking pressure max: 280 bar
SunSource Distribution Division: SunSource
Price:Â Requires Quote
