2180-FFSÂ NOSHOKÂ |Â 2180 Series Flange-Female Stainless Steel Valve Type Meter 2 Manifold Valve with Soft Seat
Manufacturer:Â NOSHOK
Manufacturer Model #:Â 2180-FFS
- Designed for use with orifice meters
- 100% helium leak tested to 1 x 10-4 ml/s for guaranteed performance and reliability
- Replaceable Acetal seat and straight through porting for bidirectional, high capacity flow and easy roddable cleaning
- Body Material:Â Zinc-nickel plated steel, electropolished 316 Stainless SteelCategory:Â 2180 Series Meter 2 Manifold Valves with Soft SeatConnection Size:Â 1/4Connection Type:Â National Pipe Thread (NPT)Flow Coefficient Cv:Â 0.76Installed Options and Accessories:Â PackingPTFE Manifold Gasket Ring (RG1-TF1)Graphite Manifold Gasket (RG1-GF1) Traditional to Coplanar Flange Adapter (TCA-S)Options:Â Panel mountings, o-ring materials, handles, packings, regulating stem and stem tipsOrifice Size:Â 0.187Pressure Rating at 200 Degree Fahrenheit (F) Temperature:Â 6,000Process Type:Â Meter ManifoldRelated Items:Â MK4-CS, 5 Valve Steel Mounting Kit|MK4-SS2, 5 Valve 304 Stainless Steel Mounting KitSchemaID:Â 106318Seat:Â Soft SeatSeries:Â 2-ValveStem Seal and Type:Â All 316 Stainless Steel stems with Fluorocarbon (FKM) o-ring and Polytetrafluoroethylene (PTFE) back-up ring below the threads, Polytetrafluoroethylene (PTFE) packing optionalSyndication:Â 1Type:Â Manifold ValveUnit:Â 1Valve Material:Â Stainless SteelValve Type:Â Flange-Female
SunSource Distribution Division: SunSource
$620.29
