630AW00606AÂ DANFOSSÂ |Â HPR075L0S1MAAHAC0000000A
Manufacturer:Â DANFOSS
Manufacturer Model #:Â 630AW00606A
EATON DURAFORCE HPR SERIES OPEN CIRCUIT PISTON PUMPS
Displacements: 55cc to 280cc (3.57 to 17.1 cu in)|Operating Pressure: 420 bar (6100 psi)|Quiet Operation: 70% pressure pulse reduction with SPU
Displacements: 55cc to 280cc (3.57 to 17.1 cu in)|Operating Pressure: 420 bar (6100 psi)|Quiet Operation: 70% pressure pulse reduction with SPU
- Application:Â Construction, Agriculture, Truck and Bus, Oil and Gas, and other mobile applicationsCode title:Â Open Circuit Piston PumpController type:Â Pressure and Flow Compensator with .4375-20 SAE O-Ring Load Sense Port Left SideDesign code11:Â ADisplacement:Â 75 cubic centimetre per revolutionEccn:Â EAR99Fluid cleanliness:Â 18/16/13Front mounting:Â StandardHousing material:Â Cast IronIcc2:Â Mobile - OC Piston PumpsIdentification:Â EatonInput shaft:Â 14 Tooth 12/24 DpInput speed maximum:Â 2500 revolutions per minuteMaximum case drain temperature:Â 90 degree CelsiusMaximum displacement setting:Â 75 cubic centimetre per revolutionMaximum input power:Â 132.8 kilowattMaximum input torque:Â 4487 inch pound (pound inch)Maximum recommended operating viscosity:Â 30 centistokesMinimum recommended operating viscosity:Â 15 centistokesModel Code:Â HPR075L0S1MAAHAC0000000AF0000000A000AANominal pressure rating:Â 6091 psiPaint:Â Anti Rust Conservation OilPeak pressure rating:Â 7251 psiProduct height:Â 11.54Product height uom:Â inchProduct length:Â 15.23Product length uom:Â inchProduct trade name:Â HPR SeriesProduct weight:Â 39.00Product weight uom:Â poundProduct width:Â 14.50Product width uom:Â inchPump special features:Â NoneShaft rotation:Â LeftSub brand:Â DuraForce
SunSource Distribution Division: SunSource
