SunSource | 6423-155 DANFOSS Industrial Hydraulics

Images are representative only. Please verify with our technical experts as actual product may differ.

6423-155 DANFOSS | HYDRAULIC PUMP

Manufacturer: DANFOSS

Manufacturer Model #: 6423-155

EATON SERIES 1 HEAVY DUTY CLOSED CIRCUIT PUMP SERVO CONTROL
Proven reliability in demanding applications|Multiple control options|Pro-FX ready

: Application: Construction, Agriculture, Truck and Bus, Oil and Gas, and other mobile applications
Auxiliary mounting: SAE B Pad; With Shaft Seal (Dry)
Charge pressure relief valve setting: 15 bar
Charge pump: Charge Pump With Remote Pressure Filter Ports On -A- Port Side
Charge pump displacement: 27.9 cubic centimetre per revolution
Charge pump special features: None
Configuration: Single
Control: Hydraulic Remote 1.4-14.1 Bar (20-205 PSI) With Wide Band Neutral
Design code11: B
Design type: Series 1
Displacement: 105.4 cubic centimetre per revolution
Documentlink 2d drawings 4: http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/a-1363-001.pdf
Documentlink 2d drawings 5: http://wcm-prod-cs.etn.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/103067-000.pdf
Drive shaft seal configuration: Single
Eccn: EAR99
Flow at rated speed and psi: 375 litre per minute
Icc2: Mobile - CC Piston Pumps
Identification: Standard
Input shaft: 14 Tooth 12/24 Pitch Spline
Main port orientation: Radial
Main port s: [1.00] - Code 61 Per SAE J518
Maximum input torque: 441 newton metre
Minimum working pressure: 420 bar
Model Code: ACA642314L0A00HB000000AB40D00000B
Mounting flange location: Standard J744
Paint: Finish Blue
Product height: 12.26
Product height uom: inch
Product length: 18.46
Product length uom: inch
Product trade name: Series 1
Product weight: 85.30
Product weight uom: pound
Product width: 11.96
Product width uom: inch
Shaft rotation: Left
Special features17: None
Special pump assembly features: None
Sub brand: None
Type: Variable Displacement
Valve plate: Standard, V-Groove
Working pressure max: 480 bar
: Documentlink catalog 1

SunSource Distribution Division: SunSource

Price:

Requires Quote
