6423-186 DANFOSS | M64 FC V/P TANDEM RS

Manufacturer: DANFOSS

Manufacturer Model #: 6423-186

EATON SERIES 1 HEAVY DUTY CLOSED CIRCUIT PUMP SERVO CONTROL
Proven reliability in demanding applications|Multiple control options|Pro-FX ready

: Application: Construction, Agriculture, Truck and Bus, Oil and Gas, and other mobile applications
Auxiliary mounting: SAE B Pad; No Shaft Seal (Wet)
Charge pressure relief valve setting: 23 bar
Charge pump: Charge Pump With External Discharge Port With 90 Degree; 7/8-14 UNF; 37 Degree Flare Tube Fitting
Charge pump displacement: 34.7 cubic centimetre per revolution
Charge pump special features: Steel Core Charge Pump Gasket
Configuration: Single
Control supply orifice diameter: 0.073 inch
Design code11: B
Design type: Series 1
Displacement: 105.4 cubic centimetre per revolution
Documentlink user guides 1: http://www.eaton.com/ecm/groups/public/@pub/@eaton/@hyd/documents/content/pll_1500.pdf
Drive shaft seal configuration: Single
Eccn: EAR99
Flow at rated speed and psi: 375 litre per minute
Icc2: Mobile - CC Piston Pumps
Identification: Standard
Input shaft: 14 Tooth 12/24 Pitch Spline
Main port orientation: Radial
Main port s: [1.00] - Code 61 Per SAE J518
Maximum input torque: 441 newton metre
Minimum working pressure: 420 bar
Model Code: ACA642314L0A00MAG002L0FF50KA1500B
Mounting flange location: Standard J744
Paint: Finish Blue
Pressure override setting port a: 379 bar
Product height: 12.26
Product height uom: inch
Product length: 18.71
Product length uom: inch
Product trade name: Series 1
Product weight: 85.30
Product weight uom: pound
Product width: 11.96
Product width uom: inch
Shaft rotation: Left
Special features17: None
Special pump assembly features: Rear Pump Unit For Tandem Assembly (No Shaft Seal)
Sub brand: None
Type: Variable Displacement
Valve plate: Standard, V-Groove
Working pressure max: 480 bar
: Documentlink catalog 1
