TVWS HYDROKRAFT - CC PISTON PUMPS

HC806186000777
  • Adjustment stops: None
  • Application: Marine, Tunnel Boring Machine Etc.
  • Configuration: Single
  • Control options: None
  • Control type: None
  • Customer adjustment specification: No
  • Design code11: 10
  • Displacement: 500 cubic centimetre per revolution
  • Drive shaft seal configuration: Single
  • Eccn: EAR99
  • Housing material: Cast Iron
  • Icc2: HydroKraft - CC Piston Pumps
  • Main drive shaft end: KEYED SHAFT ISO
  • Main port orientation: Radial
  • Main port s: A & B PORTS SAE, METRIC THREAD
  • Model Code: TVWS500M08R000001R01SVMA00SPB00C0000000000000000067610
  • Mounting flange: ISO 3019/2-200B4HW
  • Paint: Blue
  • Product height: 20.47
  • Product height uom: inch
  • Product length: 26.76
  • Product length uom: inch
  • Product trade name: W Series
  • Product weight: 924.00
  • Product weight uom: pound
  • Product width: 20.47
  • Product width uom: inch
  • Seal material16: Viton
  • Series: Variable
  • Series type: W
  • Shaft rotation: Right
  • Special features17: Yes
  • Sub brand: Hydrokraft
  • Thru drive options20: None
  • Transmission block configuration: No Transmission Circuit
  • Yoke position indicator: Sensor And Position Indicator
  • Zero position valve: No
EATON HYDROKRAFT W SERIES TRANSMISSION PUMPS
Compact size|Tandem mounting|Oversized shaft and shaft bearings
